The Siemens 6ES7315-7TJ10-0AB0 is a central processing unit designed for the SIMATIC S7-300 PLC series, providing reliable control and advanced technology functions for industrial automation environments. Equipped with a 384 KB work memory, this CPU handles complex processing tasks efficiently. It features three integrated communication interfaces: a first interface for MPI/DP up to 12 Mbit/s, a second DP interface for drive applications, and a third Ethernet PROFINET interface with a 2-port switch for seamless network integration. The 6ES7315-7TJ10-0AB0 supports integrated I/O specifically for technology-oriented applications and requires a 40-pole front connector and a Micro Memory Card of at least 8 MB for operation. This Siemens unit is built for demanding production environments where performance and reliability are critical.
Specifications:
Manufacturer: Siemens
Range: Simatic S7
Subrange: S7-300
Type of product: Standard CPUs
Supply voltage: 19,2-28,8V DC
PLM Product phase: Phase-Out
Supply voltage: 19,2-28,8V DC
Digital inputs: 4
Digital outputs: 8
Model: Compact
Logistics Dimensions (cm): 15,5 x 13,1 x 12,8
Weight: 0.72kg
Commodity Code: 85371091
Export Control Regulations (ECCN): 9N9999
EAN: 4025515082552
