The Siemens 6ES7314-6CF01-0AB0 is a compact and versatile PLC from the SIMATIC S7-300 series, designed for industrial automation and advanced process control. This model integrates a CPU 314C-2DP with MPI communication, offering 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, one PT100 input, and four fast counters capable of up to 60 kHz. It features an integrated PROFIBUS DP interface and a built-in 24V DC power supply, making it suitable for complex production environments that demand robust performance and reliable connectivity. The 6ES7314-6CF01-0AB0 includes a 48 kB working memory and requires a micro memory card for operation. The front connector, with a 40-pin configuration, eases installation and maintenance in control cabinets.
Specifications:
Manufacturer: Siemens
Range: Simatic S7
Subrange: S7-300
Type of product: Power supplies
Supply voltage: 24V DC
PLM Product phase: Obsolete
Successor: 6ES7314-6CF02-0AB0
Predecessor: 6ES7314-6CF00-0AB0
Supply voltage: 24V DC
Analogue inputs: 4
Analogue outputs: 2
Digital inputs: 24
Digital outputs: 16
Model: Compact
Logistics Dimensions (cm): 15,1 x 13,4 x 13,2
Weight: 0.75kg
Commodity Code: 85371091
Export Control Regulations (ECCN): N
EAN: 4025515069690
