The Siemens 6ES7314-6BF01-0AB0 is a compact SIMATIC S7-300 CPU 314C-2 PTP designed for demanding industrial automation applications. This unit integrates a wide range of digital and analog inputs and outputs, including 24 digital inputs, 16 digital outputs, 4 analog inputs, and 2 analog outputs. Additionally, it features one PT100 sensor input and four fast counters capable of processing signals up to 60 kHz, providing flexible control for various automation tasks. The built-in RS485 interface and MPI communication enable smooth integration into existing networks, while the integrated 24V DC power supply simplifies installation. The 6ES7314-6BF01-0AB0 includes a generous 48 KB working memory, ensuring reliable performance for complex processes. Front connectors (2 x 40-pin) are included, and a micro memory card is required for operation.
Specifications:
Manufacturer: Siemens
Range: Simatic S7
Subrange: S7-300
Type of product: Power supplies
Supply voltage: 24V DC
PLM Product phase: Obsolete
Successor: 6ES7314-6BF02-0AB0
Predecessor: 6ES7314-6BF00-0AB0
Supply voltage: 24V DC
Analogue inputs: 4
Analogue outputs: 2
Digital inputs: 24
Digital outputs: 16
Model: Compact
Logistics Dimensions (cm): 15,5 x 13,4 x 13,1
Weight: 0.76kg
Commodity Code: 85371091
Export Control Regulations (ECCN): N
EAN: 4025515069683
